FI Pro Dash Touch Screen Digital Dashboard with High Resolution 6.86 Screen (Holley Part #553-112). The Holley new 6.86 Pro Dash delivers over 200 monitoring channels of reliable real-time data in a more compact, full HD package suitable for nearly any motorsports application. Be assured that the Holley? FI 6.86 Pro Dash will deliver the vitals you need! The 6.86 Pro Dash is completely customizable for use in a variety of motorsports applications. It features a 6.86 1280×480 resolution low glare, high brightness, high contrast, full color capacitive touch screen for easy viewing even in sun, plug & play connection to all Holley? FI systems & a weather resistant aluminum housing featuring flexible mounting options. FI 6.86 Pro Dash also features a plethora of Input and Outputs for expanded functionality of your Holley? The included 34pin connector has 13 multi-configurable inputs for most Holley? FI sensors, such as pressure and temperature. We still have you covered, these inputs are configurable, allowing you to utilize different sensor scaling calibrations! The Pro Dash also features two dedicated speed inputs, for RPM, Driveshaft speed, or any other Hall effect speed input. The Pro Dash contains 4 ground switched outputs, that can be utilized with the switch panel feature to quickly turn on any of your auxiliary accessories, such as a master nitrous switch, or an electric water pump. We have also integrated a 10-LED Programmable shift light into the bezel of the dash and added 4 optional LED’s that can be programmed for virtually anything, such as fuel pressure or oil pressure warning indicators, or a target boost indicator, the options are almost endless. NOTE: This device will only display and/or communicate with Holley? C Us with V4 build 110 or later firmware. It will also communicate with Terminator X / Terminator X Max and Sniper? Plug & Play Display support for Dominator, HP, Terminator X & Sniper? Integrated 10-LED Programmable shiftlight with 4-LED warning indicators for other sensor inputs. Capable of monitoring up to 238 real-time values like RPM/TPS/Boost. 10 default background skins pre-loaded. Quickly swipe between multiple active screens? Une, warm-up, race, drive, etc. Virtual switch panel eliminates the need for external toggle switches. Manual or auto-brightness features. Built-in GPS with odometer function (Antenna included). On-screen datalog playback features. Expandable storage via USB. No stylus required, capacitive touch. User definable channel alarms & warnings. 4x 10-32 mounting holes for surface or flush mounting w/ hardware included. USB Keyboard & Mouse functionality. 34 Pin Wiring Harness contains Power, Ground & CANbus connections. Input/output functionality for 13 multi-configurable inputs & 4 ground switched outputs. User defined alarms for any input. Up-gradable with future software enhancements. Viewing area – 6.86 diagonally. Dash weight – 1.2 lbs. Product Type: Digital Dashes. Screen Size: 6.86. Screen Type: Capacitive Touch Screen. You can view and download the complete assembly instruction booklet for this? You can view and download the Quick Start Guide. You can view and download the Wiring & Setup. We also have thousands of other High Performance Parts in our store. We want you to have the parts as bad as you do. This item is in the category “eBay Motors\Parts & Accessories\Car & Truck Parts & Accessories\Interior Parts & Accessories\Gauges\Individual Gauges”. The seller is “kratter” and is located in this country: US. This item can be shipped to United States, Canada, United Kingdom, Denmark, Romania, Slovakia, Bulgaria, Czech Republic, Finland, Hungary, Latvia, Lithuania, Malta, Estonia, Australia, Greece, Portugal, Cyprus, Slovenia, Japan, China, Sweden, Korea, South, Indonesia, Taiwan, South Africa, Thailand, Belgium, France, Hong Kong, Ireland, Netherlands, Poland, Spain, Italy, Germany, Austria, Bahamas, Israel, Mexico, New Zealand, Singapore, Switzerland, Norway, Saudi Arabia, Ukraine, United Arab Emirates, Qatar, Kuwait, Bahrain, Croatia, Republic of, Malaysia, Brazil, Chile, Colombia, Panama, Jamaica, Barbados, Bangladesh, Bermuda, Brunei Darussalam, Bolivia, Ecuador, Egypt, French Guiana, Guernsey, Gibraltar, Guadeloupe, Iceland, Jersey, Jordan, Cambodia, Cayman Islands, Liechtenstein, Sri Lanka, Luxembourg, Monaco, Macau, Martinique, Maldives, Nicaragua, Oman, Peru, Pakistan, Paraguay, Reunion, Vietnam, Uruguay.
- Manufacturer Part Number: 553-112
- Brand: Holley Performance Products
